Sealed Industrial Gauges, Liquid Filled, available from OCI Instruments Inc.

Application: For neutral media such as air, water, oil, steam and other inert liquids and gases compatible with brass and bronze on medium to heavy duty industrial service. Liquid filled for locations where vibration or pulsation would cause excessive wear to a dry gauge.

Click to enlarge

Click to enlarge

>Note: Line drawings for configurations R and S in size 2�" are available on request

Click to enlarge

Click to enlarge

Click to enlarge
